Velotric Thunder 1

Technical Specifications
-
FRAMESET
Frame6061 Triple-Butted Aluminum Alloy Frame, Integrated Cable Routing, Internal Battery, Flat Mount Disc, Rack and Fenders Compatible
Fork6061 Aluminum Alloy, Internal Brake Routing, 12x100mm Thru-axle, 1-1/4” to 1-1/8” Tapered Steerer，Fenders Compatible
ELECTRONICS
Motor Hub350W, Peak 600W, 45Nm
Battery36V, 9.8Ah, 352.8Wh
CellSamsung 21700
Charger36V, 2.0A, Operates on 100V-240V AC, 50-60Hz
Charging Time0-80% 4 Hours, 0-100% 6 Hours
Sensor2-Side Torque sensor
Control PanelFingerprint Unlock
Automatic Rider Recognition
Battery Indicator
PAS Indicator
Auto Headlight
Auto Brightness Control
SecurityTheft Alert, GPS-Tracking, Fingerprint and Bluetooth Unlock
HeadlightLight Sensing, 6v/3w/45Lux High-Output Integrated LED, Adjustable Angle
Pedal AssistEco, Tour, Normal, Sport and Turbo Pedal Assist
Walk Mode2.9 MPH
Water ResistantIPX6
WEIGHT& LOAD
Bike Weight36lbs
Max Bike Load330lbs
ACCESSORIES
FendersSupported, buy separately from VELOTRIC
Rear RackSupported, buy separately from VELOTRIC
Range Extender36V, 4.9Ah, 176.4Wh
SPEED & RANGE
Max Speed20 MPH, Class 1
Max Speed (Unlock)25 MPH
Max RangeUp to 70 miles
ChainringsPROWHEEL Pro Aluminum Alloy, 40T Narrow Wide Chainring
CranksetAluminum Alloy, 170mm
CassetteSHIMANO 8 Speeds, 11-32T
Rear DerailleurSHIMANO M310-8
Shift LeverSHIMANO M315-8
ChainKMC Z8.3
BRAKE
BrakeTEKTRO HD-R280 Hydraulic Disc Brake
Rotors160mm Front and Rear
Brake LeversTEKTRO HD-R280 Aluminum Alloy, with adjustable reach
WHEEL
Rims700c Disc, Double-Wall Aluminum Alloy, Pinned (F) 24 Hole / (R) 28 Hole
Front HubNOVATEC Aluminum Alloy J-Hook Disc Hub,12x100mm Thru-Axle
Tire700x38c Ebike Puncture Resistant Tires
COCKPIT
Handlebars6061 Aluminum Alloy, Φ31.8mm, 680mm
GripsVELOTRIC Sports Grips
Stem6061 Aluminum Alloy, 3D-Forged Alloy, 8-Degree Rise, 31.8mm Clamp, Garmin Mount Compatible
SaddleSELLE ROYAL SRX
Seat Post6061 Aluminum Alloy, 30.9 x 300mm
SUPPORTS
Phone MountAdapt GoPro/Garmin
PedalsAluminum Alloy
KickstandAluminum Alloy
